HellermannTyton Tredux Tubo termorretráctil de pared fina 3:1, 6,0mm, negro, 10m 319-00607

Electricians and maintenance technicians rely on HellermannTyton Tredux thin wall heat shrink tubing for dependable insulation and protection in wiring harnesses, control panels, and automotive repairs. This black tubing shrinks at a 3:1 ratio, conforming tightly over irregular shapes and connectors.

Key specifications

• Supplied inner diameter: 6.0 mm
• Recovered inner diameter: 2.0 mm
• Recovered wall thickness: 0.50 mm
• Length: 10 m
• Colour: Black
• Material: Cross-linked polyolefin
• Shrink ratio: 3:1
• Operating temperature: -55°C to +135°C
• Minimum shrink temperature: +90°C
• Dielectric strength: >20 kV/mm
• Flammability rating: UL224 VW-1 (self-extinguishing)
• Halogen-free

Why choose it

The Tredux series offers a balance of flexibility and mechanical strength. Its cross-linked polyolefin construction provides good chemical resistance and UV resistance in black, making it suitable for demanding environments. The 3:1 shrink ratio ensures a secure fit over components with varying diameters.

Ideal use cases

• Insulating electrical splices and terminations
• Bundling and protecting wire harnesses
• Strain relief for connectors and cable entries
• Colour coding for circuit identification

Good to know

The tubing is RoHS compliant and meets UL224 125°C VW-1 and CSA standards. It is supplied in a continuous 10 m length, allowing you to cut it to the exact size needed for each application.
