K2 Systems Dome FixPro L Placa base de montaje 200x200mm (modelo 2004144)

The K2 Dome FixPro L base plate stands apart from generic mounting brackets through its system-specific engineering for K2 Dome FixPro rails and clamps. Crafted from high-quality aluminium EN AW-6063 T66, it delivers an excellent strength-to-weight ratio and natural corrosion resistance, making it a reliable foundation for flat roof solar installations on bitumen, foil, concrete, or green roofs. Its 200x200mm footprint and low 30mm height allow easy handling and positioning, while pre-drilled holes ensure straightforward integration into both ballasted and mechanically fixed configurations.

Highlights

• System-specific design: Seamlessly integrates with K2 Dome FixPro rails and clamps.
• High-quality aluminium EN AW-6063 T66: Excellent strength-to-weight ratio and natural corrosion resistance.
• Versatile mounting: Suitable for ballasted and mechanically fixed installations on flat roofs.
• Proven reliability: TÜV Rheinland certified system component for outdoor and industrial use.
• Complete package: Includes one base plate, ready for connection to other system elements.

In daily use

Installation is straightforward thanks to the pre-drilled holes and universal compatibility with K2 Dome FixPro system rails. The plate's compact dimensions and low height make it easy to handle and position, whether securing it to concrete ballasts or fixing it directly to the roof membrane. Once in place, it provides a rock-solid anchor point that withstands wind uplift and thermal expansion, ensuring your solar array stays secure for decades.

Full specifications

• Product Type: Base Plate / Support
• System Series: K2 Dome FixPro
• Application: Flat Roof Solar Mounting
• Roof Compatibility: Bitumen, Foil, Concrete, Green Roofs
• Material: Aluminium EN AW-6063 T66
• Mounting Principle: Ballasted or Mechanically Fixed (as part of system)
• Length: 200 mm
• Width: 200 mm
• Height: 30 mm
• Corrosion Resistance: Excellent
• UV Resistance: Yes
• Color: Silver (Natural Aluminium)
• Manufacturer Part Number (MPN): 2004144
• EAN: 4251786204458
• Installation Type: Component for modular system
• Certifications: TÜV Rheinland certified system component
• Usage Environment: Outdoor, industrial
• Compatibility: Designed for K2 Dome FixPro system rails and clamps
• Fastening Method: Bolt/screw connections to other system components

Final note

With TÜV Rheinland certification and a design tailored for the K2 Dome FixPro system, this base plate offers a dependable, corrosion-resistant anchor for flat roof solar projects, ensuring long-term stability and performance.
