Kern CK 50-Y4 Célula de carga de punto único, capacidad 50 kg, OIML R60 C3, IP65, aleación de aluminio

The Kern CK 50-Y4 stands out as a precision single point load cell engineered for compact weighing platforms up to 400 x 400 mm. With a 50 kg nominal capacity and OIML R60 C3 accuracy class, it delivers consistent, repeatable results in demanding industrial and commercial environments.

Highlights

• Nominal load: 50 kg
• Accuracy class: OIML R60 C3
• Rated output: 2.0 ± 0.002 mV/V
• Input resistance: 400 ± 20 Ω
• Output resistance: 350 ± 3 Ω
• Insulation resistance: ≥ 5000 MΩ at 50 V DC
• Excitation voltage: 5–12 V DC (max 18 V DC)
• Operating temperature: -10 °C to +40 °C
• Compensated temperature: -10 °C to +40 °C
• Material: aluminum alloy
• Protection class: IP65
• Cable length: 3 m
• Maximum platform size: 400 x 400 mm
• Safe overload: 150 % of nominal load
• Ultimate overload: 200 % of nominal load
• Non-linearity: ± 0.020 % F.S.
• Hysteresis: ± 0.020 % F.S.
• Creep: ± 0.020 % / 30 min

In daily use

This load cell is built for reliable performance in bench scales, counting scales, and checkweighers. The aluminum alloy body keeps weight low while maintaining structural integrity, and the IP65 rating allows use in dusty or wash-down environments. The 3 m cable provides flexibility for installation, and the wide excitation voltage range ensures compatibility with most weighing indicators.

Full specifications

• Load cell type: single point
• Nominal load (capacity): 50 kg
• Accuracy class: OIML R60 C3
• Rated output (sensitivity): 2.0 ± 0.002 mV/V
• Input resistance: 400 ± 20 Ω
• Output resistance: 350 ± 3 Ω
• Insulation resistance: ≥ 5000 MΩ (at 50 V DC)
• Excitation voltage: 5–12 V DC (max 18 V DC)
• Operating temperature range: -10 °C to +40 °C
• Compensated temperature range: -10 °C to +40 °C
• Material: aluminum alloy
• Protection class: IP65
• Cable length: 3 m
• Maximum platform size: 400 x 400 mm
• Safe overload: 150 % of nominal load
• Ultimate overload: 200 % of nominal load
• Non-linearity: ± 0.020 % F.S.
• Hysteresis: ± 0.020 % F.S.
• Creep: ± 0.020 % / 30 min

Final note

For precise and durable weighing in compact systems, the Kern CK 50-Y4 delivers certified accuracy and dependable construction.
