Kit de cables RAID FUJITSU PY-CBS118 para tarjeta RAID – cables de conexión internos

RAID cable kit FUJITSU PY-CBS118 for RAID card — internal interconnect cables supplies the internal cabling required to connect a Fujitsu RAID controller to compatible storage devices inside server enclosures. The kit is designed to match Fujitsu connector pinouts and signal requirements, enabling proper communication between the RAID card and drives while maintaining the compact routing and secure connections expected in server environments.

Advantages

The cable kit provides cables manufactured to match Fujitsu RAID card connector layouts and signal integrity standards, reducing the risk of miswiring or signal degradation. Cables are sized and terminated for internal server use, allowing tidy cable routing and secure connections. Using original-compatible internal interconnects helps preserve warranty conditions and ensures predictable performance when installing or replacing a RAID controller.

Suitable for

• Internal connection of Fujitsu RAID controllers to SATA or SAS storage backplanes in servers
• Server maintenance and component replacement where original-style cabling is required
• System upgrades that involve swapping or adding RAID cards in compatible Fujitsu systems
• Data center racks and enterprise servers needing reliable internal interconnects

Key specifications

• Cable type: internal interconnects for RAID controller to drive/backplane connections
• Connector compatibility: designed to mate with Fujitsu RAID card internal connectors and matching drive/backplane sockets
• Signal support: suitable for high-speed SATA/SAS signalling used by RAID controllers
• Form factor: compact internal cable routing with secure latch-style terminations
• Intended environment: enterprise server chassis and rack-mounted systems

How to use

Power down the server and follow electrostatic discharge precautions before installing the cables. Route each cable from the RAID card slot to the target drive or backplane connector, aligning the keyed connectors and seating them until the latch engages. Avoid sharp bends and excessive tension on the cable; secure routing with existing chassis tie points or cable management clips. After installation, verify connections in system firmware or RAID management software and perform a functional check to confirm the RAID card recognizes connected drives.

Recommendations

Use the cables only inside the server chassis and avoid exposure to high temperatures or moisture. Replace any cable showing visible damage or connector wear. For best results, pair the kit with compatible Fujitsu RAID controllers and backplanes and follow server manufacturer guidance when performing firmware or hardware changes.
