Placa base i71265U 32 yA YdTL3 yAB

When a laptop motherboard fails, the entire system becomes unusable, halting productivity and risking data loss. This Lenovo system board, featuring an Intel Core i7-1265U processor and 32GB of soldered LPDDR5 memory, is a direct replacement for the Dell Latitude 5430, restoring your laptop to full functionality with enhanced performance for demanding business tasks.

Who is it for

IT technicians and system integrators who need a reliable, high-performance motherboard to repair or upgrade Dell Latitude 5430 laptops. It's ideal for businesses that require consistent performance across fleets, ensuring minimal downtime and maximum productivity.

Main features

• Intel Core i7-1265U processor with 10 cores (2 performance, 8 efficient) and 12 threads, up to 4.8 GHz turbo for seamless multitasking.
• 32GB LPDDR5 onboard memory, soldered for stability and energy efficiency, supporting intensive applications.
• Integrated Intel Iris Xe Graphics for crisp visuals and support for up to 4K displays via HDMI or DisplayPort over USB-C.
• One M.2 NVMe PCIe Gen4 x4 slot for ultra-fast SSD storage, plus an M.2 slot for Wi-Fi/Bluetooth card.
• Comprehensive connectivity: USB 3.2 Gen 1 Type-A, USB 3.2 Gen 2 Type-C with Thunderbolt 4, Gigabit Ethernet, and audio jacks.
• UEFI firmware for secure boot and modern management features.

Specifications

• Processor: Intel Core i7-1265U (12th Gen, Alder Lake)
• Memory: 32GB LPDDR5 (soldered, non-upgradeable)
• Storage: 1x M.2 NVMe PCIe Gen4 x4 slot
• Graphics: Intel Iris Xe Graphics (integrated)
• Network: Gigabit Ethernet (Wi-Fi via M.2 card, not included)
• Ports: USB 3.2 Gen 1 Type-A, USB 3.2 Gen 2 Type-C (Thunderbolt 4), HDMI, headphone/mic combo
• Form Factor: Proprietary laptop motherboard for Dell Latitude 5430
• Condition: New

Tips

Before installation, ensure the laptop is powered off, battery disconnected, and you are properly grounded to prevent electrostatic damage. Transfer any necessary components like the Wi-Fi card and SSD from the old board. After installation, update the BIOS to the latest version for optimal compatibility and performance.
