LevelOne fuente de alimentación industrial 48V DC, 48V DC, 40W, carril DIN

LevelOne fuente de alimentación industrial 48V DC, 48V DC, 40W, carril DIN
LevelOne fuente de alimentación industrial 48V DC, 48V DC, 40W, carril DIN
116,07 €
The POW-4811 is a DIN-rail industrial power supply is ruggedized, universal input voltage range and full compliance with all important safety and EMC standards. It can be operated at full load across an ambient temperature range of -20 to 70 Celsius degree without need of additional cooling to guara... Leer más
Stock 1 Código 2399286 Marca LEVELONE Modelo POW-4811 Garantía 2 años

Envíos y devoluciones

Entrega estimada Viernes, Octubre 23
Te mantendremos informado a través de nuestro sistema de seguimiento detallado
Opciones de pago
Tarjeta bancariaVisaMastercardPayPalApple PayGoogle PayTransferencia bancaria
The POW-4811 is a DIN-rail industrial power supply is ruggedized, universal input voltage range and full compliance with all important safety and EMC standards. It can be operated at full load across an ambient temperature range of -20 to 70 Celsius degree without need of additional cooling to guarantee quality for harsh industrial environment. Moreover, this power unit has been designed specifically for use with Infinity Industrial PoE Ethernet series, also it meets the requirements for both PoE and PoE Plus as well.

LevelOne 48V DC Industrial Power Supply, 48V DC, 40W, DIN-Rail. Total power: 39.8 W, AC input voltage: 85 - 264 V, Peak power: 40 W. Mean time between failures (MTBF): 301700 h. Product colour: Blue, White. Safety: UL508, TUV EN60950-1 Approved,EN55011, EN55022 (CISPR22), EN61204-3 Class B,EN61000-4-2, 3, 4, 5,.... Width: 90 mm, Depth: 40 mm, Height: 100 mm

Aspectos destacados
  • Universal AC Input at Full Range
  • Short Circuit, Overload / Over Voltage Protection
  • Fanless Design
  • Supports DIN-rail installation
  • 100% Full Load Burn-in Test
  • DC OK Relay Contact
Especificaciones
Altura
100 mm
Altura del embalaje
40 mm
Ancho
90 mm
Ancho del embalaje
90 mm
Características técnicas
48V DC Out
Código del Sistema Armonizado (HS)
84733020
Color del producto
Blue, White
Conectores de alimentación periféricos (Molex) (4 pines)
0
Corriente máxima
0.83 A
Funciones de protección eléctrica
Over voltage, Overload, Short circuit
Humedad relativa de funcionamiento (H-H)
20 - 90%
Indicadores LED
Yes
País de origen
China
Peso
300 g
Peso del embalaje
350 g
Potencia máxima
40 W
Potencia total
39.8 W
Profundidad
40 mm
Profundidad del embalaje
100 mm
Seguridad
UL508, TUV EN60950-1 Approved,EN55011, EN55022 (CISPR22), EN61204-3 Class B,EN61000-4-2, 3, 4, 5, 6, 8, 11, ENV50204, EN55024, EN61000-6-2, EN61204-3 heavy
Temperatura de funcionamiento (T-T)
-20 - 70 °C
Tensión de entrada de CA
85 - 264 V
Tiempo medio entre fallos (MTBF)
301700 h

Folleto

Abrir documento
