MEAN WELL IRM-10-24 - 10 W - 85 - 264 V - ITE EN/UL/IEC 60950 - negro - 25,4 mm - 45,7 mm

Powering low-voltage electronics from the mains often means bulky adapters or unreliable boards. The MEAN WELL IRM-10-24 solves this with a compact, encapsulated AC/DC module that delivers a stable 24 VDC at up to 10 W directly on your PCB. Its universal input (85–264 VAC) and full safety certifications make it a drop-in power source for industrial controls, IoT devices, and instrumentation.

Who is it for

Engineers and system integrators needing a reliable, board-mounted power supply for ITE applications. Ideal for smart home hubs, sensors, automation controllers, and any project requiring a safe, low-profile 24 V rail without external adapters.

Main features

• Universal AC input (85–264 VAC) and DC input (120–370 VDC) for worldwide use
• Encapsulated plastic case with PCB mount pins for direct integration
• High efficiency up to 85% and low no-load consumption (<0.1 W)
• Full protection: short circuit, overload, and over voltage
• Complies with UL60950-1, EN60950-1, IEC60950-1 safety standards
• Wide operating temperature range: -30 °C to +70 °C

Specifications

• Output power: 10 W
• Output voltage: 24 VDC
• Output current: 0.42 A
• Isolation voltage: 3 kVAC
• Ripple & noise: 150 mVp-p (max)
• Cooling: free air convection
• Dimensions: 45.7 mm × 25.4 mm × 21.5 mm (L × W × H)
• Weight: 32 g

Tips

Mount the module on a PCB with adequate clearance for heat dissipation. For best EMI performance, follow the recommended input filtering in the datasheet. Ensure the ambient temperature stays within the derating curve for full power output.
