MEAN WELL XLG-75-24-A controlador LED 75W IP20 100-305V 24V

The MEAN WELL XLG-75-24-A is an AC-DC single-output LED driver delivering 75W in constant power mode with built-in active PFC. It accepts a wide AC input range (100–305V) and provides a stable 24V DC output at up to 3.1A. The unit has a metal housing with compact dimensions (63 × 140 × 32 mm) and an IP20 protection rating, designed for indoor LED lighting installations. A built-in potentiometer allows basic output adjustment.

Advantages

This LED driver offers constant power operation and integrated power factor correction for improved mains compatibility. The compact metal enclosure supports reliable heat dissipation, and the built-in potentiometer enables straightforward output fine-tuning without external tools. Wide input voltage range makes it suitable for varied supply conditions while providing a stable 24V output.

Suitable for

• Indoor LED strips and modules requiring 24V DC
• Architectural lighting and accent lighting
• Retrofit LED drivers in commercial and residential fixtures

Key specifications

• Brand: MEAN WELL
• Model: XLG-75-24-A
• Output: 24V DC, up to 3.1A (75W)
• Input voltage: 100–305V AC
• Operating mode: Constant Power Mode with built-in PFC
• Housing: Metal
• Protection rating: IP20 (indoor use)
• Dimensions: 63 × 140 × 32 mm

How to use

Mount the driver in a dry, ventilated indoor location with adequate clearance for heat dissipation. Connect the AC mains input (100–305V) and the 24V DC output to the LED load following wiring polarity. Use the built-in potentiometer to adjust output within the driver’s specified range if minor tuning is required. Ensure load does not exceed the 75W / 3.1A rating.

Recommendations

Install and service the driver only according to local electrical regulations. Avoid outdoor or wet-location installation due to the IP20 rating, and provide sufficient ventilation to maintain operating temperature within manufacturer limits.
