Accesorio de iluminación MEAN WELL APV-12-24 blanco 90-264V 47-63Hz

The MEAN WELL APV-12-24 is a 24V constant-voltage power supply designed for lighting and signage applications. It accepts a universal AC input of 90–264V at 47–63Hz and is built in a fully isolated plastic case. The compact dimensions (77 × 29 × 40 mm) and wide operating temperature range (-30 to 70 °C) make it suitable for installations in confined spaces and varied environments.

Advantages

APV-12-24 provides stable 24V constant-voltage output with built-in protections against short circuit, overload and overvoltage. The unit uses free-air convection cooling, undergoes a 100% full-load burn-in test, and is offered with a two-year warranty. Its small size and simple design deliver cost-effective and reliable operation for LED lighting and moving sign systems.

Suitable for

• LED strips and LED modules requiring 24V constant voltage
• Illuminated moving signs and channel letters
• Tight or enclosed installations where compact dimensions are needed

Key specifications

• Output voltage: 24V constant voltage
• AC input: 90–264V, 47–63Hz
• Protections: short circuit, overload, overvoltage
• Cooling method: free air convection
• Dimensions: 77 × 29 × 40 mm
• Operating temperature: -30 to 70 °C
• Humidity: 20–90% RH
• Warranty: 2 years

How to use

Install the APV-12-24 in a dry, well-ventilated location with sufficient clearance for convection cooling. Connect the AC input to a 90–264V AC source and the DC output to the 24V LED load, observing correct polarity. Verify the load does not exceed the unit’s rated output current and ensure wiring is secure before powering on. Allow the device to operate within the specified temperature and humidity ranges.

Recommendations

For reliable long-term operation, avoid installing the power supply in sealed enclosures without ventilation, limit exposure to dust and corrosive atmospheres, and ensure connected LED loads match the 24V constant-voltage output and current capacity of the APV-12-24.
