Merten 290425 Mecanismo de toma Schuko, blanco polar (RAL 9010), empotrar, 16 A, 250 V, IP20, bornes de tornillo, System M

Schuko socket outlet insert from Merten System M, engineered for reliable power distribution in residential and commercial installations. This flush-mounted insert delivers a secure connection for Type F plugs with a nominal rating of 16 A and 250 V AC, ensuring compatibility with standard European appliances. The polar white (RAL 9010) glossy finish blends seamlessly with Merten frames, while the halogen-free thermoplastic construction provides durability and safety.

Advantages

The central earth contact and screw terminals (up to 2 x 2.5 mm² rigid) guarantee stable and code-compliant wiring. The shatterproof, UV-resistant material withstands daily use, and the IP20 rating suits indoor dry environments. Its compact 21 mm mounting depth fits standard flush boxes, and it integrates with 1-gang to 5-gang System M frames for flexible design.

Suitable for

• Residential living rooms, bedrooms, and kitchens
• Office workstations and meeting rooms
• Hotels and public buildings with flush-mounted wiring
• Renovation projects requiring a classic white finish

Key specifications

• Socket type: Schuko (Type F)
• Nominal voltage: 250 V AC
• Nominal current: 16 A
• Connection: Screw terminals, up to 2 x 2.5 mm²
• Material: Halogen-free thermoplastic, shatterproof
• Colour: Polar white (RAL 9010), glossy
• Protection: IP20
• Mounting: Flush-mounted, depth approx. 21 mm
• Frame compatibility: Merten System M, 1-gang to 5-gang
• Operating temperature: -5 °C to 40 °C

Recommendations

Pair with Merten System M frames in matching polar white for a cohesive look. For enhanced safety in homes with children, consider adding a separate child-protection cover, as this insert does not include an integrated shutter.
