METZ Connect UPk Unidad de conexión empotrable, caja de conexión universal, diseño IAE, 2x RJ45, bornes de tornillo RJ45 mini borne (130040111-I)

In-wall network cabling often leaves an unsightly mess of loose cables and unreliable terminations. The METZ Connect UPk Flush-Mount Connection Unit solves this by providing a clean, professional-grade junction point for two RJ45 data connections, designed to fit standard IAE/UAE frames. It terminates solid or stranded twisted-pair cables securely via screw terminals, ensuring stable 10 Gigabit Ethernet performance in a compact, flush-mounted form.

Who is it for

This unit is for electricians, network installers, and homeowners who need a reliable, aesthetically pleasing in-wall data outlet for high-speed networks. It is ideal for new installations or retrofits where a universal, tool-friendly termination is preferred.

Main features

• Two RJ45 ports in a single flush-mount housing.
• IAE/UAE design compatible with 50x50 mm central plates and 80x80 mm outer frames.
• Screw terminal (LSA-Plus compatible) for solid wires AWG 24/1 to 22/1 and stranded wires AWG 26/7 to 22/7.
• Supports 10GBASE-T up to 500 MHz (Cat.6A / Class EA).
• Shielded housing with gold-plated contacts for reliable signal integrity.
• Pure white (RAL 9010) finish blends with standard wall plates.
• Supports Power over Ethernet (PoE, PoE+, 4PPoE).

Specifications

• Product type: Data outlet / connection unit
• Mounting type: Flush-mount (Unterputz)
• Number of ports: 2
• Connector type (front): RJ45
• Performance category: Cat.6A (Class EA)
• Transmission speed: 10 Gigabit Ethernet (10GBASE-T)
• Shielding: Shielded
• Internal connection: LSA-Plus compatible screw terminals
• Wire gauge (solid): AWG 24/1 to AWG 22/1
• Wire gauge (stranded): AWG 26/7 to AWG 22/7
• Wiring scheme: T568A and T568B compatible
• Design compatibility: IAE/UAE (50x50 mm central plate, 80x80 mm outer frame)
• Colour: Pure White (RAL 9010)
• Housing material: Plastic
• Contact material: Gold-plated contacts
• Power over Ethernet: PoE, PoE+, 4PPoE
• Standards: ISO/IEC 11801, EN 50173-1, TIA/EIA-568-C.2
• Operating temperature: -40°C to +70°C
• Insertion cycles: >750

Tips

For best performance, use shielded Cat.6A cable and ensure proper grounding of the shield at the patch panel. The screw terminals allow re-termination without special tools, making it easy to correct wiring mistakes.
