MINIS FORUM X1 Pro-470 Ryzen AI 9 HX470 Barebone Mini PC

The MINIS FORUM X1 Pro-470 is a high-performance barebone mini PC powered by the AMD Ryzen AI 9 HX470 processor, designed for demanding computing tasks. With its compact form factor and robust connectivity, it is ideal for professionals, content creators, and tech enthusiasts seeking a powerful yet space-saving solution.

Advantages

Equipped with the latest AMD Ryzen AI 9 HX470 processor featuring 12 cores and 24 threads, boost clock up to 5.1 GHz, and integrated NPU delivering up to 50 TOPS for AI acceleration. The AMD Radeon 890M graphics with 16 compute units provide excellent visual performance. Supports dual-channel DDR5-5600MHz memory up to 96GB and dual M.2 NVMe SSD slots (PCIe 4.0 and PCIe 5.0) for lightning-fast storage. Connectivity includes Wi-Fi 7, Bluetooth 5.4, dual 2.5 Gigabit Ethernet, dual USB4 Type-C (40Gbps, DP Alt Mode, PD), HDMI 2.1, and multiple USB ports. The aluminum alloy chassis ensures durability and efficient heat dissipation.

Suitable for

• Professional workstations for video editing, 3D rendering, and software development
• Home office and enterprise desktop replacement
• AI and machine learning development
• Gaming and entertainment

Key specifications

• Processor: AMD Ryzen AI 9 HX470 (12 cores, 24 threads, up to 5.1 GHz)
• Graphics: AMD Radeon 890M (16 CUs)
• Memory: 2x DDR5-5600MHz SODIMM slots, max 96GB
• Storage: 1x M.2 2280 PCIe 4.0, 1x M.2 2280 PCIe 5.0
• Wireless: Wi-Fi 7 (802.11be), Bluetooth 5.4
• Ethernet: 2x 2.5 Gigabit RJ45
• Video Output: 2x HDMI 2.1, 2x USB4 (DP Alt Mode)
• USB Ports: 2x USB4 Type-C, 3x USB 3.2 Gen2 Type-A, 1x USB 2.0 Type-A
• Audio: 3.5mm combo jack
• Power: 19V DC-IN external adapter
• Chassis: Aluminum alloy, active cooling
• Operating System: None (Barebone)

Recommendations

This barebone system requires installation of DDR5 SODIMM memory and M.2 NVMe SSD. Compatible with Windows 11, Linux, or other operating systems. Ideal for users who want to customize their configuration.
