MITON MT-P134-B Caja de superficie IP65 gris ABS

The MITON MT-P134-B is a robust surface-mounted enclosure designed for electrical installations, electronics housing, and junction boxes. Manufactured from high-quality ABS plastic, it offers excellent durability and protection in demanding environments. With an IP65 rating, it is dust-tight and protected against water jets, making it suitable for indoor and outdoor use.

Advantages

This enclosure provides reliable protection for electrical components thanks to its IP65 ingress protection and IK07 impact resistance. The UV-resistant and chemically resistant ABS material ensures long-lasting performance even in harsh conditions. The solid lid with 4-screw fastening guarantees a secure seal, while internal mounting points allow for easy installation of PCBs or mounting plates.

Suitable for

• Electrical installations in industrial and commercial settings
• Electronics housing for control systems and sensors
• Junction boxes for wiring connections
• Outdoor applications requiring weatherproof protection

Key specifications

• Material: ABS Plastic
• Ingress Protection: IP65
• External Dimensions (L x W x H): 130 x 80 x 70 mm
• Internal Dimensions (L x W x H): Approx. 122 x 72 x 65 mm
• Colour: Light Grey (RAL 7035)
• Lid Type: Solid with 4 Screws
• Mounting: Surface Mounting
• Operating Temperature: -25°C to +70°C
• Flammability Rating: UL94-HB
• Impact Resistance: IK07
• Glow Wire Test: 650°C
• Internal Mounting Points: Yes

Recommendations

For optimal installation, use appropriate cable glands and mounting accessories. Ensure the enclosure is securely fixed to a flat surface to maintain the IP65 seal. Suitable for a wide range of electrical and electronic applications where protection against dust and water is required.
