MITON P130U Caja de derivación empotrada naranja 60mm

The MITON P130U is a high-quality flush-mounted junction box designed for reliable electrical installations. Manufactured from durable polypropylene (PP), this round box offers excellent mechanical strength and self-extinguishing properties, ensuring safety and longevity. With a diameter of 60 mm and a depth of 40 mm, it is ideal for mounting switches, sockets, and as a junction box in residential and commercial buildings.

Advantages

Self-extinguishing material provides enhanced fire safety. Multiple knock-out entries (20 mm diameter) allow flexible cable routing. The orange color makes it easily identifiable in walls. Complies with PN-EN 60670-1 standard for flush-mounting boxes.

Suitable for

• Flush-mounted electrical installations
• Mounting switches and sockets
• Junction boxes for cable connections
• Indoor use in dry environments (IP20)

Key specifications

• Brand: MITON
• Model: P130U
• Type: Flush-mounted junction box
• Shape: Round
• Diameter: 60 mm
• Depth: 40 mm
• Material: Polypropylene (PP)
• Color: Orange
• IP Rating: IP20
• Temperature range: -5°C to +60°C
• Entry diameter: 20 mm
• Self-extinguishing: Yes
• Standard: PN-EN 60670-1
• Series: P

Recommendations

For complete installation, use with compatible covers and screws (sold separately). Ensure proper cable management and secure mounting in accordance with local electrical codes.
