Módulo transceptor SFP BlueOptics SFP100FX1310-TSC-2KM-BO 155 Mbit/s 1310 nm

The BlueOptics SFP100FX1310-TSC-2KM-BO is a fiber optic SFP transceiver module for 100BASE-FX networks. It supports a maximum data transfer rate of 155 Mbit/s over multi-mode fiber at a wavelength of 1310 nm. The module is housed in a compact metal casing, weighs approximately 3 g, uses a 3.3 V supply and features an LC duplex optical connector following MSA form factor standards. It is compatible with devices that accept SFP 100BASE-FX transceivers and is intended for point-to-point fiber links up to 2 km.

Advantages

The transceiver provides stable optical transmission at 1310 nm and supports standard SFP interfaces for straightforward hot-plug installation. Its metal housing offers mechanical durability and EMI shielding while the lightweight design facilitates integration in switch, router or storage hardware. The module conforms to common MSA specifications, enabling interoperability with equipment that supports 100BASE-FX SFP modules. Built-in digital diagnostic capabilities may be available when supported by the host hardware for real-time monitoring of supply voltage, laser bias, output and receive power and temperature.

Suitable for

Key specifications

How to use

Install the BlueOptics SFP100FX1310-TSC-2KM-BO by inserting it into an open SFP slot on compatible network equipment while the device is powered according to the host vendor's instructions. Connect LC duplex fiber patch cables with correct polarity to the transmitter and receiver ports. Configure the host device for 100BASE-FX operation if required and verify link status through the device management interface. If the host supports digital diagnostics (DDM/DOM), enable or read diagnostic parameters to monitor module health and link conditions.

Recommendations

Use matched fiber type and quality (as recommended by the network design) and maintain proper connector cleanliness to ensure optimal signal quality; verify host compatibility and DDM/DOM support before deployment to access monitoring features.
