Phoenix Contact 1401682 tope final para bornes de carril DIN, gris, 5 uds.

Terminal blocks on DIN rails can shift or loosen over time, especially in environments with vibration or frequent wiring changes. The Phoenix Contact 1401682 end clamp solves this by locking terminal blocks firmly in place on the rail, preventing movement and ensuring a stable, reliable connection.

Who is it for

This end clamp is for electricians, panel builders, and maintenance technicians who work with DIN rail-mounted terminal blocks. It is suitable for industrial control panels, automation systems, and any application where terminal blocks must stay securely fixed.

Main features

• Secures terminal blocks on standard DIN rails NS 35/7.5 and NS 35/15
• Made from gray polyamide (PA) with high mechanical strength
• Compact design: 42 mm length, 5.1 mm width, 35 mm height
• Wide operating temperature range from -60 °C to 105 °C
• UL 94 V0 flammability rating for enhanced fire safety
• Pack of 5 pieces for multiple installations

Specifications

• Product type: End clamp
• Mounting type: DIN rail mount
• DIN rail compatibility: NS 35/7.5, NS 35/15
• Material: Polyamide (PA)
• Color: Gray
• Length: 42 mm
• Width: 5.1 mm
• Height: 35 mm
• Operating temperature: -60 °C to 105 °C
• Flammability rating: UL 94 V0
• Insulating material group: I (IEC 60664)
• RoHS compliant: Yes

Tips

Install the end clamp at the end of a terminal block row after all blocks are positioned. Tighten the clamp screw until the blocks are firmly held against the rail. For high-vibration environments, use one clamp at each end of the row for maximum stability.
