PLANET IMG-2100T Convertidor de medios Gigabit industrial, 1x RJ45 a 1x SFP, -40 a 75 °C

The PLANET IMG-2100T is a rugged industrial-grade media converter designed to extend network distances by converting 10/100/1000BASE-T copper to 100/1000BASE-X fiber via an SFP slot. With a wide operating temperature range and IP30 metal housing, it is ideal for harsh environments.

Advantages

Reliable and cost-effective solution for integrating fiber into existing copper networks. Supports jumbo frames up to 10K bytes and features DIP switch for LFP, fiber speed, and auto/force mode. Redundant DC power input ensures uptime.

Suitable for

• Industrial automation and control networks
• Surveillance and security systems
• Smart grid and utility applications
• Outdoor and extreme temperature installations

Key specifications

• 1 x 10/100/1000BASE-T RJ45 port
• 1 x 100/1000BASE-X SFP slot (SFP module not included)
• Conversion: Copper to Fiber
• Jumbo frame support: up to 10K bytes
• Power input: 12-48V DC redundant terminal block
• Power consumption: max 3.84W
• Operating temperature: -40 to 75°C
• IP30 metal case, DIN-rail / wall-mount
• ESD and surge protection: 6KV DC
• Unmanaged, plug-and-play

Recommendations

For optimal performance, use PLANET SFP modules (e.g., MGB-GT, MGB-SX, MGB-LX). Ensure proper grounding and power supply redundancy for mission-critical applications.
