PSG 60.041 soporte de rodillo guía 100x60 mm acero galvanizado

Mounting bracket for sliding gate systems, providing a robust and corrosion-resistant foundation for guide rollers. Its galvanized steel construction ensures long-lasting performance in outdoor environments, maintaining proper gate alignment and smooth operation.

Advantages

The bracket features a 5 mm thick steel base plate measuring 100 x 60 mm, offering a stable platform for secure mounting. Four mounting holes (two on the base, two on the vertical arm) with 11 mm diameter accommodate M10 bolts, allowing for straightforward bolt-on installation. The galvanized finish protects against rust, extending the product's lifespan even in harsh weather conditions.

Suitable for

• Sliding gate systems requiring guide roller support
• Outdoor environments exposed to moisture and temperature variations
• Installations with M10 or M12 guide roller mounting bolts

Key specifications

• Material: Galvanized steel (zinc-plated)
• Base plate dimensions: 100 x 60 mm
• Material thickness: 5 mm
• Overall height (projection): 60 mm
• Number of mounting holes: 4 (2 base, 2 vertical arm)
• Mounting hole diameter: 11 mm (suitable for M10 bolts)
• Corrosion resistance: Yes
• Installation method: Bolt-on
• Series: PSG Gate Components

Recommendations

For optimal performance, pair this bracket with compatible PSG guide rollers and use M10 galvanized bolts for installation. Regularly inspect the bracket for signs of wear or loosening, especially in high-traffic gate applications.
