PULS MiniLine ML50.102 fuente de alimentación para carril DIN 12V DC 4,2A 50W

Industrial control systems often face unstable input voltages and require reliable, compact power conversion on standard DIN rails. The PULS MiniLine ML50.102 addresses this by delivering a regulated 12 V DC output with 4.2 A current and 50 W power from a wide AC or DC input range.

Who is it for

This power supply is intended for automation engineers, panel builders, and machine integrators who need a space-saving, high-efficiency DIN rail power supply for industrial control cabinets, sensors, actuators, and other 12 V DC loads.

Main features

• Output: 12 V DC, 4.2 A, 50 W
• Wide input range: 100–240 V AC (85–264 V AC) or 110–150 V DC (90–300 V DC)
• High efficiency up to 89.5%
• Compact DIN rail mounting on TS35/7.5 or TS35/15
• Overload protection with constant current limiting and short circuit protection
• Low ripple and noise: <50 mVpp
• Operating temperature: -10°C to +70°C
• Screw terminal connections

Specifications

• Input frequency: 45–65 Hz
• Protection class: IP20
• MTBF: >1,000,000 h

Tips

Ensure adequate ventilation around the unit when operating at full load in high ambient temperatures. Use appropriate wire sizes for screw terminals to maintain reliable connections.
