Pulsar AWO300 carcasa de alarma negra chapa de acero 0,8 mm IP20 montaje en pared

The Pulsar AWO300 is a robust and reliable alarm enclosure designed for surface or wall mounting. Manufactured from 0.8 mm thick steel sheet with a black powder-coated finish (RAL 9005), it provides a secure housing for alarm systems, access control, and CCTV components. The enclosure features a key lock with two included keys and a tamper protection microswitch (NC contact) for enhanced security. With multiple knock-out cable entries and ventilation openings, it ensures easy installation and proper airflow. The internal mounting plate allows for convenient PCB or module installation. Operating temperature range: -10°C to +40°C. CE certified with a 2-year warranty.

Advantages

Durable steel construction with powder coating ensures long-lasting protection. Tamper-proof design with microswitch adds security. Versatile cable entries simplify wiring. Ventilation prevents overheating of internal components.

Suitable for

• Alarm systems
• Access control systems
• CCTV installations
• Security system components

Key specifications

• Material: Steel sheet, 0.8 mm thickness
• Colour: Black (RAL 9005)
• Protection class: IP20
• Tamper protection: Microswitch (NC contact)
• Mounting: Surface / wall mount
• Lock: Key lock, 2 keys included
• Cable entries: Multiple knock-out holes
• Ventilation: Yes
• Operating temperature: -10°C to +40°C
• Internal mounting plate: Yes
• Finish: Powder coated
• Certifications: CE
• Warranty: 2 years

Recommendations

For optimal security, install the enclosure in a dry indoor location. Use the provided keys to secure the lock. Ensure all cable entries are properly sealed to maintain IP20 protection.
