Relé en miniatura para PCB Finder 30.22.7.012.0020 DPDT 2A 12V DC

Miniature PCB relay with DPDT contacts, capable of switching up to 2 A at 250 V AC. The Finder 30 Series relay features a 12 V DC coil with only 200 mW power consumption and a wash-tight RT III enclosure for reliable through-hole mounting.

Advantages

Silver nickel contacts ensure long electrical life of 100,000 operations at full load. The relay withstands 2.5 kV AC insulation between coil and contacts, and operates in temperatures from -40°C to +85°C.

Suitable for

• Industrial control systems
• Automation equipment
• Signal switching in PCBs

Key specifications

• Coil voltage: 12 V DC
• Contact configuration: DPDT (2 Form C)
• Max switching current: 2 A
• Max switching voltage: 250 V AC / 220 V DC
• Coil power: 200 mW
• Mounting: Through-hole PCB
• Operating temperature: -40°C to +85°C

Recommendations

Ideal for applications requiring a compact, energy-efficient relay with high insulation and wash-tight sealing.
