RF Venue CP Beam Antena direccional Helix 470-698 MHz

The RF Venue CP Beam is a high-performance directional helical antenna designed for professional wireless microphone and in-ear monitor systems. Operating across the UHF frequency range of 470-698 MHz, it delivers exceptional gain and rejection to ensure reliable signal transmission in demanding live sound, broadcast, and event environments.

Advantages

With a gain of 9.2 dBic and a 60-degree beamwidth, the CP Beam focuses RF energy precisely, reducing interference and extending range. Its right-hand circular polarization (RHCP) minimizes multipath distortion and polarization mismatch, making it ideal for touring and fixed installations. The weather-resistant ABS construction ensures durability in outdoor use.

Suitable for

• Wireless microphone systems (UHF)
• In-ear monitor (IEM) systems
• Live sound reinforcement
• Broadcast and production
• Fixed or temporary outdoor setups

Key specifications

• Antenna Type: Helical Directional
• Frequency Range: 470-698 MHz
• Polarization: Right-Hand Circular (RHCP)
• Gain: 9.2 dBic
• Beamwidth: 60 degrees (nominal)
• Impedance: 50 Ohms
• VSWR: < 1.5:1
• Connector: BNC Female
• Mounting Thread: 5/8"-27
• Material: Durable ABS Plastic
• Weather Resistance: Yes
• Included Accessories: Stand Adapter

Recommendations

For optimal performance, pair the CP Beam with compatible UHF receivers and use proper RF distribution. The included stand adapter allows easy mounting on standard microphone stands.
