Router de sobremesa DrayTek Vigor 2866AX Dualband-Wi-Fi 6

The DrayTek Vigor 2866AX is a tabletop DSL firewall router for small and medium businesses, combining a built-in G.fast-capable DSL modem with an additional configurable Ethernet WAN and dual-band Wi‑Fi 6. The integrated DSL modem is backward compatible with VDSL2 profile 35b supervectoring and ADSL2+. The device supports load-balancing and failover to maintain business continuity and includes hardware acceleration to preserve traffic-control features while improving throughput.

Advantages

The router provides fiber-like DSL performance up to 1 Gbps on a supported DSL line and Gigabit Ethernet ports for fast wired connectivity. It includes comprehensive security and management functions—VPN, firewall, content filtering, QoS and bandwidth management, captive hotspot portal, and traffic monitoring—while offering VoIP-first priority and configurable QoS classes for business-critical applications. Models in the series are available with built-in 802.11ax wireless.

Suitable for

• Small and medium-sized offices requiring reliable wired and wireless connectivity
• Locations using DSL (G.fast, VDSL2, ADSL2+) with need for high throughput
• Environments needing VPN, firewall and content filtering for security
• Setups that require load balancing and failover between DSL and Ethernet WAN
• Deployments prioritizing VoIP and business-critical applications with QoS

Key specifications

• WAN: G.fast-supported DSL WAN (built-in modem), configurable Ethernet WAN
• Wi‑Fi: Dual-band Wi‑Fi 6 (802.11ax), up to 2402 Mbit/s on 5 GHz
• Ethernet: Gigabit Ethernet LAN with 5 RJ‑45 ports
• Security: VPN, firewall, content filtering, WPA3/WPA2/WPA/WEP support
• Other: Hardware acceleration for high performance, USB port, 2 external antennas
• Compatibility: VDSL2 profile 35b supervectoring and ADSL2+

How to use

Install the Vigor 2866AX on a stable surface and connect the DSL line to the built-in modem or use the Ethernet WAN port for an alternate uplink. Connect client devices to the Gigabit LAN ports or to the 2.4/5 GHz Wi‑Fi networks. Access the web-based management interface to configure WAN settings, set up VPNs, define firewall and content-filtering rules, and create QoS classes. Use the load-balancing and failover settings to combine or protect WAN links, and enable hardware acceleration to maintain throughput with traffic controls enabled.

Recommendations

Reserve bandwidth for high-priority QoS classes (for example VoIP and critical business apps) and allow lower-priority traffic to use remaining capacity when available; keep router firmware up to date and configure secure WPA3 or WPA2 encryption for wireless networks.
