SCHELINGER A15-SL8-ZI piloto de señalización LED verde 230V AC IP65 montaje 22mm

In industrial environments, clear and immediate status indication is critical for safe and efficient operation. The SCHELINGER A15-SL8-ZI LED signal lamp provides a reliable green light signal for control panels, machinery, and automation systems. Its robust construction and bright LED ensure visibility even in demanding conditions, helping operators quickly identify machine states and process statuses.

Who is it for

This signal lamp is ideal for electrical engineers, panel builders, and maintenance technicians who require a durable and energy-efficient indicator for industrial control systems, production lines, and equipment monitoring. It suits applications where a clear green indication is needed to signal normal operation, readiness, or safe conditions.

Main features

• Bright green LED illumination for high visibility
• 230V AC operating voltage, directly compatible with standard industrial power
• Compact 22mm panel mounting diameter, fits standard cut-outs
• IP65 ingress protection, resistant to dust and water jets
• Long lifespan of over 30,000 hours, reducing maintenance
• Low power consumption (<20 mA), energy-efficient
• Screw terminal connection for secure wiring
• Durable polycarbonate lens and plastic housing
• Wide operating temperature range from -25°C to +55°C
• CE and RoHS certified for quality and environmental compliance

Specifications

• Brand: SCHELINGER
• Model: A15-SL8-ZI
• MPN: A15-SL8-ZI
• EAN: 5900280982162
• Product Type: LED Signal Lamp
• Light Colour: Green
• Operating Voltage: 230V AC
• Frequency: 50/60 Hz
• Mounting Diameter: 22 mm
• Mounting Type: Panel Mount
• Light Source: LED
• Ingress Protection: IP65
• Operating Temperature: -25°C to +55°C
• Lifespan: >30,000 hours
• Current Consumption: <20 mA
• Connection Type: Screw Terminals
• Housing Material: Plastic
• Lens Material: Polycarbonate
• Insulation Voltage: 250V
• Certifications: CE, RoHS
• Illumination Type: Steady
• Application: Industrial, Control Panels, Machinery

Tips

Ensure the panel cut-out is exactly 22mm for a secure fit. For outdoor or washdown areas, verify that the IP65 rating meets your environmental requirements. Use appropriate wire gauges for the screw terminals to ensure reliable connections. Consider using multiple colours of the SL8 series to indicate different machine states.
