Schletter Solar ClampFit 130004-200 abrazadera universal para módulos fotovoltaicos con marco (30-50 mm), aluminio anodizado negro

Securing framed PV modules to mounting rails often requires multiple clamp types and complicated assembly. The Schletter Solar ClampFit 130004-200 solves this by providing a single universal clamp that works as both a middle and end clamp, simplifying installation and reducing inventory.

Who is it for

Solar installers and system integrators who need a reliable, corrosion-resistant clamp for framed modules with frame heights between 30 and 50 mm. It is compatible with Schletter mounting systems such as Eco, Pro, and FixGrid.

Main features

• Universal design: functions as both middle and end clamp
• Fits module frame heights from 30 to 50 mm
• High-strength aluminum body with black anodized finish
• Stainless steel M8 hexagon socket head cap screw
• Top-down installation for quick assembly
• High corrosion and UV resistance
• Compatible with portrait and landscape module orientation

Specifications

• Clamp type: Universal module clamp
• Application: Framed PV modules
• Module frame height range: 30 - 50 mm
• Material (clamp body): High-strength aluminum
• Surface finish: Black anodized
• Screw material: Stainless steel (A2)
• Screw type: Hexagon socket head cap screw M8
• Required tool: Hex key SW13
• Compatibility: Schletter Eco, Pro, FixGrid systems
• Installation method: Top-down
• Color: Black
• System series: Schletter ClampFit

Tips

Refer to the Schletter installation manual for the correct tightening torque. Use a hex key SW13 for the M8 screw. The clamp can be used in both portrait and landscape module orientations.
