Schwaiger Adaptador de enchufe (clavija doméstica) para carril eléctrico modular, negro (MSPS0230)

With a connection attenuation of just 1.5 dB across all ports, the Schwaiger MSPS0230 base module keeps signal loss to a minimum in your CATV or broadband network. This flush-mount unit splits a single coaxial input into three dedicated outputs: TV, radio, and data/modem.

Overview

The MSPS0230 is the foundation of the Schwaiger MSPS modular system. It accepts a coaxial cable via screw terminals and distributes the signal to an IEC male TV output, an IEC female radio output, and an F-connector female data output. The module supports TV frequencies from 47 to 862 MHz, radio from 87.5 to 108 MHz, and data return/forward paths of 5-65 MHz and 108-862 MHz respectively.

What stands out

• Three outputs: TV, radio, and data/modem
• Low 1.5 dB connection attenuation on all ports
• High shielding effectiveness >75 dB (Class A)
• 75 Ohm impedance for standard CATV systems
• Flush-mount design for standard wall boxes

Technical details

• Input: screw terminal for coaxial cable
• Output 1: TV (IEC male)
• Output 2: Radio (IEC female)
• Output 3: Data/Modem (F-connector female)
• Frequency range TV: 47-862 MHz
• Frequency range radio: 87.5-108 MHz
• Frequency range data return path: 5-65 MHz
• Frequency range data forward path: 108-862 MHz
• Connection attenuation: 1.5 dB (all outputs)
• Return loss: >10 dB
• Shielding effectiveness: >75 dB (Class A)
• Impedance: 75 Ohm
• Mounting type: flush-mount

Our verdict

The Schwaiger MSPS0230 delivers clean signal separation with minimal loss, making it a reliable core for modular antenna socket installations.
