Sensor óptico de eje Z Flashforge G3 (MPN 70001994002) para impresora 3D

Flashforge G3 Z-axis optical sensor is a replacement accessory designed for compatible Flashforge G3 series 3D printers. It performs optical position detection for the printer Z-axis, helping to achieve more consistent bed leveling and improved layer alignment. The sensor is intended for maintenance, repair, or upgrade of machines that support this sensor interface and mounting arrangement.

Advantages

The optical detection method offers non-contact position sensing that reduces mechanical wear compared with physical switches. Integration with the Z-axis control enables finer repeatability in vertical movement and supports consistent first-layer height across prints. The sensor is compact and made to match the form factor and electrical connections of compatible Flashforge G3 systems, facilitating straightforward replacement without extensive modification.

Suitable for

• Repairing or replacing a faulty Z-axis sensor on Flashforge G3 series 3D printers
• Upgrading existing machines to restore accurate Z positioning and bed leveling
• Routine maintenance to ensure continued print quality and layer consistency

Key specifications

• Function: Optical position detection for Z-axis
• Compatibility: Designed for Flashforge G3 series 3D printers (mechanical and electrical compatibility required)
• Mounting: Compact form factor matching original sensor mounting points
• Signal type: Digital optical output compatible with printer control electronics
• Operation: Non-contact sensing to minimize mechanical wear

How to use

Power off the printer and follow the manufacturer service manual for safe disassembly of the Z-axis cover or carriage. Remove the existing sensor by disconnecting its electrical connector and unfastening any mounting screws or clips. Fit the Flashforge G3 Z-axis optical sensor into the original mounting location, secure it with the appropriate fasteners, and reconnect the electrical cable following the original wiring orientation. After reassembly, power on the printer and run the printer's sensor calibration or bed leveling routine to verify correct operation and adjust trigger height if required.

Recommendations

Use genuine or compatible replacement parts according to the printer manufacturer's instructions. Confirm electrical and mechanical compatibility before installation. Perform calibration and test prints after installation to ensure correct Z-axis behavior and adjust settings in firmware or printer software if necessary.
