SHIVERPEAKS S-Conn 05-02004 divisor VGA de 4 puertos 250 MHz amplificador distribuidor de vídeo activo

Distribute one VGA signal to four displays simultaneously with crystal-clear quality up to 1920 x 1440 @ 60Hz. The SHIVERPEAKS S-Conn 05-02004 is an active video splitter with a 250 MHz bandwidth, ensuring sharp images even over long cable runs—up to 65 m input and 50 m output. Ideal for classrooms, conference rooms, and digital signage.

Overview

The SHIVERPEAKS S-Conn 05-02004 is a robust 1-in/4-out VGA distribution amplifier housed in a durable metal enclosure. It accepts a single VGA input and boosts the signal to four VGA outputs, maintaining signal integrity without degradation. The active amplification compensates for signal loss over extended distances, making it perfect for large venues or complex setups. Plug-and-play installation requires no drivers or software, and the included DC 9V power adapter ensures reliable operation.

What stands out

• High bandwidth of 250 MHz supports resolutions up to 1920 x 1440 @ 60Hz, including VGA, SVGA, XGA, UXGA, and QXGA standards.
• Active signal amplification allows input cable lengths up to 65 m and output cable lengths up to 50 m without quality loss.
• Metal housing provides durability and effective heat dissipation for continuous use.
• LED indicators for power and port activity simplify monitoring and troubleshooting.
• Wide compatibility with PCs, laptops, projectors, and monitors featuring VGA interfaces.

Technical details

• Input: 1 x VGA (HD15 Female)
• Output: 4 x VGA (HD15 Female)
• Maximum resolution: 1920 x 1440 @ 60Hz
• Video bandwidth: 250 MHz
• Power supply: DC 9V (AC adapter included)
• Housing material: Metal
• Colour: Black
• Operating temperature: 0°C to 70°C
• Storage temperature: -20°C to 85°C
• Plug & Play: Yes

Our verdict

The SHIVERPEAKS S-Conn 05-02004 delivers reliable, high-quality VGA distribution for professional AV installations. Its active amplification and rugged build make it a dependable choice for extending video signals across multiple displays without compromise.
