Siemens SIRIUS ACT 3SU1200-6KB10-1AA0 Avisador acústico, 22 mm redondo, plástico, negro, 24 V AC/DC, IP66/IP67/IP69K

With a sound pressure level of approximately 80 dB at 10 cm, this acoustic annunciator delivers clear audible signaling in industrial control panels. The Siemens SIRIUS ACT 3SU1200-6KB10-1AA0 is a 22 mm round acoustic annunciator with a plastic housing in black, designed for panel mounting.

Overview

This device is part of the SIRIUS ACT series and provides a continuous tone when activated. It operates on 24 V AC/DC and draws a maximum current of 40 mA. The front of the unit is rated IP66, IP67, and IP69K, making it suitable for demanding environments, while the rear is rated IP20.

What stands out

• High degree of protection on the front: IP66, IP67, IP69K
• Wide operating temperature range from -25°C to +70°C
• Long electrical lifetime of 100,000 hours at 24 V DC
• Simple screw terminal connection for easy wiring

Technical details

• Product type: Acoustic annunciator
• Series: SIRIUS ACT
• Mounting diameter: 22 mm
• Design: Round
• Housing material: Plastic
• Housing colour: Black
• Tone type: Continuous tone
• Operating voltage: 24 V AC/DC
• Current consumption: max. 40 mA
• Sound pressure level: approx. 80 dB (at 10 cm)
• Connection type: Screw terminal
• Degree of protection (front): IP66, IP67, IP69K
• Degree of protection (rear): IP20
• Operating temperature range: -25 to +70 °C
• Storage temperature range: -40 to +80 °C
• Mounting type: Panel mount
• Lifetime (electrical): 100,000 hours (at 24 V DC)
• Approvals: CE, UL, CSA, CCC, EAC

Our verdict

A robust and reliable acoustic signaling device for industrial applications, offering high ingress protection and a long service life.
