Splitter HDMI ShiverPeaks SP05-03008 1x8 Metal 4K 30Hz

ShiverPeaks SP05-03008 1x8 Metal 4K 30Hz is an HDMI splitter that duplicates a single HDMI source to eight independent HDMI outputs. Housed in a metal chassis, the device is designed to distribute video and audio signals from one player, PC or media device to multiple displays simultaneously while supporting resolutions up to 4K at 30 Hz. The compact enclosure offers physical durability and contributes to passive heat dissipation, making it suitable for continuous operation in retail, meeting rooms, classrooms and digital signage environments.

Advantages

The metal housing increases mechanical robustness and aids thermal performance compared with plastic enclosures. The 1-to-8 configuration enables one source to feed several screens without additional conversion equipment. Support for 4K@30Hz ensures compatibility with high-definition content where higher frame rates are not required, and straightforward plug-and-play operation simplifies installation and daily use.

Suitable for

• Retail displays and product demo screens
• Classroom and lecture hall projection to multiple monitors
• Conference rooms and corporate presentations
• Digital signage installations in public spaces
• Trade shows and event booths with several displays

Key specifications

• Input/Output configuration: 1 HDMI input to 8 HDMI outputs
• Maximum supported resolution: 4K (3840 x 2160) at 30 Hz
• Audio support: HDMI embedded audio passthrough
• Housing material: metal chassis for improved durability and heat dissipation
• Installation: compact tabletop or rack-adjacent placement
• Power: external DC power supply required (included with unit)

How to use

Connect the HDMI source device (such as a media player, laptop or set-top box) to the splitter's HDMI input, then connect up to eight HDMI cables from the splitter's outputs to the displays. Attach the included external power adapter to the unit and plug it into a mains outlet. Once powered, the splitter will replicate the source signal to all connected displays. No special software is required; basic EDID negotiation is managed automatically by the device.

Recommendations

For best results use high-quality HDMI cables rated for the desired resolution and keep cable lengths within recommended ranges to avoid signal degradation. When using 4K@30Hz, ensure source device and displays support that resolution and refresh rate. Place the unit in a ventilated location to allow passive cooling of the metal chassis. For installations in noisy RF environments or long cable runs, consider shielded HDMI cabling and line conditioning to maintain signal integrity.
