Striebel & John UK648MW Media VT UP Patch Panel 4R puerta WiFi

The Striebel & John UK648MW Media VT UP Patch Panel 4R WiFi Door is a flush-mounted multimedia distribution board designed for residential and SOHO environments. It integrates a 12-port RJ45 patch panel, three Schuko sockets, and a WiFi-transparent plastic door, providing a central hub for network and power distribution.

Advantages

Space-saving flush-mounted design with a perforated, removable device mounting plate for easy installation of active network components. The WiFi-transparent door ensures optimal signal transmission while protecting equipment. Integrated ventilation slots prevent overheating.

Suitable for

• Residential multimedia distribution
• Small office/home office (SOHO) networks
• Centralized installation of routers, switches, and media converters

Key specifications

• Mounting Type: Flush-mounted (Unterputz)
• Number of Rows: 4
• Door Type: WiFi-transparent plastic door
• Enclosure Material: Steel sheet
• Door Material: Plastic
• Color: White (RAL 9010)
• Protection Class: IP30
• Rated Voltage: 230 V AC
• Rated Current: 16 A
• Number of Schuko Sockets: 3
• Integrated Patch Panel: Yes (12-port RJ45)
• Device Mounting Plate: Perforated, removable
• Cable Entry: Multiple pre-punched entries (top/bottom/sides)
• Ventilation: Integrated ventilation slots
• Usable Depth for Devices: Approx. 90 mm
• Standards: DIN VDE 0603-1, DIN 43870-1

Recommendations

Ideal for structured cabling in modern apartments and small offices. Combine with compatible patch cables and network components for a complete solution.
