Sygonix SY-6872548 cerradura electromagnética 60 kg de fuerza de retención 12 V DC Fail-Safe montaje en superficie

Securing doors, cabinets, and drawers in access control systems requires a reliable locking mechanism that holds firm under force yet releases instantly when needed. The Sygonix SY-6872548 electromagnetic lock delivers 60 kg of holding force, ensuring restricted areas stay closed until the right moment.

Who is it for

This lock suits integrators and facility managers building access control for interior doors, server racks, medicine cabinets, or tool drawers. It works where a fail-safe operation is required: when power is cut, the lock releases, allowing safe egress in emergencies.

Main features

• Electromagnetic holding force of 60 kg (approx. 600 N)
• Fail-safe operation: unlocks when power is removed
• 12 V DC operating voltage with low 120 mA current draw
• Surface mount design with aluminum alloy body and steel armature plate
• LED indicator shows lock status at a glance
• Wide operating temperature range from -10 °C to +55 °C

Specifications

• Lock Type: Electromagnetic Lock
• Holding Force: 60 kg
• Operating Voltage: 12 V DC
• Current Consumption: 120 mA
• Mounting Type: Surface Mount
• Housing Material: Aluminum Alloy
• Armature Plate Material: Steel
• LED Indicator: Yes
• Operating Temperature: -10 °C to +55 °C
• Operating Humidity: 0% to 95% non-condensing
• Lock Body Dimensions: 80 x 40 x 25 mm
• Armature Plate Dimensions: 75 x 33 x 10 mm
• Connection Type: 2-wire power

Tips

Pair this lock with a 12 V DC power supply and a door controller for a complete access solution. Ensure the armature plate aligns flush with the magnet face for maximum holding force. For fail-safe applications, connect to an uninterruptible power supply if you need the door to remain locked during brief power interruptions.
