Tarjeta de interfaz DeLOCK 90483

The DeLOCK 90483 is an internal PCIe interface card that adds one SFF-8654 connector to a desktop PC. It supports PCIe 3.0 and NVMe protocol, enabling connection of devices such as U.2 SSDs via an appropriate cable (cable not included). The card is intended for systems running Windows 10 or Windows 8.1 and is targeted at applications that require high data transfer performance.

Advantages

The card provides a single SFF-8654 port for direct connection of NVMe storage devices and delivers PCIe 3.0 bandwidth up to a combined 64 Gbit/s. It is compatible with standard PCIe slots and is designed for internal installation in desktop PCs. Support for NVMe ensures low-latency access and high throughput for supported drives.

Suitable for

Key specifications

How to use

Install the card into an available PCIe slot on the motherboard following the PC manufacturer's safety guidelines. Secure the card in the case and connect the SFF-8654 port to an NVMe device (for example a U.2 SSD) using a compatible SFF-8654 to U.2 cable (not included). After hardware installation, boot the system and install or verify drivers and firmware as required by your operating system (Windows 10 or Windows 8.1). Configure the drive in the OS storage management tools before use.

Recommendations

Use a certified SFF-8654 to U.2 cable for reliable connection. Ensure the PCIe slot provides the required lane configuration for full performance and confirm BIOS/UEFI and OS support for NVMe devices. Keep drivers and firmware up to date for optimal stability and performance.
