TELEVES Cable coaxial de toma de tierra EK1672plus negro 16 mm² X2038

For satellite and antenna installations, proper grounding is essential for safety and signal integrity. The TELEVES Koax Grounding Cable EK1672plus provides a reliable connection for potential equalization and lightning protection in TV and SAT systems. Its 16 mm² bare copper conductor ensures low resistance, while the black PVC jacket offers durability and UV resistance for outdoor use.

Key specifications

• Conductor material: Bare copper (Cu)
• Conductor cross-section: 16 mm²
• Number of cores: 1
• Jacket material: PVC
• Jacket colour: Black
• Outer diameter: 7.0 mm
• UV resistant
• Flame retardant (IEC 60332-1-2)
• Operating temperature: -30°C to +70°C
• Installation temperature: -5°C to +50°C
• Sold per meter

Why choose it

The EK1672plus is built for demanding outdoor conditions, with UV-resistant PVC and a wide operating temperature range. Its bare copper conductor provides excellent conductivity for grounding applications, and the flame-retardant jacket adds an extra layer of safety.

Ideal use cases

• Grounding satellite dishes and antennas
• Potential equalization in TV/SAT distribution systems
• Lightning protection for mast installations

Good to know

This cable is sold by the meter, allowing you to order the exact length needed for your installation. It complies with VDE 0281-13 and IEC 60332-1-2 standards.
