Toma de corriente Bachmann 946.009 2 x tipo F Acero inoxidable

The Bachmann 946.009 socket outlet combines a compact stainless steel housing with two Type F power outlets for desktop embedded installation. Designed for offices, kitchens and living rooms, this unit fits worktops or desks up to 40 mm thick and has a low mounting depth of approximately 42.5 mm, enabling installation above drawers. The matt stainless steel finish and anti-fingerprint coating reduce visible marks, while a removable cover simplifies cleaning. A square design and space-saving cable routing make the TWIST 2 variant suitable where an elegant, unobtrusive power solution is required.

Advantages

Compact dimensions and low mounting depth enable installation in worktops and desks without obstructing drawers. The matt stainless steel surface with anti-fingerprint coating keeps the unit looking clean under regular use. A removable cover makes maintenance and cleaning easier. The recessed cable routing reduces required installation space and the square form factor provides a neat, modern appearance. The unit offers two Type F outlets for simultaneous connection of multiple devices.

Suitable for

• Office desks and meeting tables
• Kitchen worktops and islands
• Living room furniture and media cabinets
• Home offices and study areas

Key specifications

• Brand: Bachmann
• Model / MPN: 946.009
• EAN: 4057298129100
• Socket type: 2 x Type F
• Material / finish: Stainless steel, matt with anti-fingerprint coating
• Mounting depth / height: approx. 42.5 mm
• Maximum desktop/worktop thickness: 40 mm
• External dimensions (W x D x H): 115 mm x 115 mm x 42.5 mm

How to use

Cut an installation hole in the worktop or desk according to the product’s dimensions, ensuring the material thickness does not exceed 40 mm. Route the power cable close to the housing and secure the unit in place following the manufacturer’s mounting instructions. After installation, connect the mains supply and test both Type F sockets with the required appliances. When the cover is opened, the outlets are accessible; close the cover by hand after use to protect the sockets and create a flush surface.

Recommendations

For safe operation, install the socket outlet in accordance with local electrical regulations and, if required, have a qualified electrician perform the mains connection. Do not exceed the rated load of connected devices and keep the removable cover in place when the unit is not in use to protect against dust and spills.
