Transceptor BlueOptics QSFP 40GBASE-LR4 Singlemode LC 10km para Check Point CPAC-TR-40LX-SSM160-QSFP-C

Network engineers deploying Check Point switches or routers in enterprise data centers can use this BlueOptics QSFP transceiver to connect over singlemode fiber at 40 Gbps across distances up to 10 km. It is compatible with the Check Point CPAC-TR-40LX-SSM160-QSFP-C and supports 40 Gigabit Ethernet, Fibre Channel, or SONET/SDH applications.

Key specifications

• Transceiver type: QSFP
• Ethernet standard: 40GBASE-LR4
• Data rate: 40 Gbps
• Fiber type: Singlemode
• Max distance: 10 km
• Wavelengths: 1271 nm, 1291 nm, 1311 nm, 1331 nm (LAN WDM)
• Connector: LC Duplex
• DDM/DOM support: Yes
• Hot-swappable: Yes
• Power consumption: < 3.5 W
• Operating temperature: 0°C to 70°C
• Laser type: DFB
• Power supply: 3.3 V

Why choose it

This transceiver is MSA compliant and follows the IEEE 802.3ba 40GBASE-LR4 standard, ensuring reliable interoperability with Check Point equipment. Digital diagnostic monitoring allows real-time performance tracking.

Ideal use cases

• 40 Gigabit Ethernet uplinks between data center switches
• Long-distance fiber connections up to 10 km
• Fibre Channel or SONET/SDH applications in enterprise networks

Good to know

The transceiver uses a duplex LC connector and operates on singlemode fiber. It is hot-swappable and supports digital diagnostics for easy maintenance.
