Triton RSX-27-XD6-CXX-A1 rack armario de pared 27U 19" 600x600mm, bastidor pivotante de dos piezas, gris claro

With a 60 kg static load capacity and 27U of internal space, the Triton RSX-27-XD6-CXX-A1 keeps your network equipment secure and accessible. The two-part swing frame design lets the front section open like a door, giving full access to the rear of your devices without removing them from the rack. The 600x600mm footprint fits standard 19-inch equipment, and the light grey (RAL 7035) powder-coated steel construction blends into any office or technical environment.

Overview

The Triton RSX-27-XD6-CXX-A1 is a 27U wall-mounted rack cabinet designed for structured cabling and network equipment in offices, server rooms, and industrial settings. Its two-part construction consists of a fixed rear section and a hinged front section that swings open, simplifying installation and maintenance. The cabinet accommodates 19-inch rack-mount devices with a usable internal depth of 470 mm, while the rear section adds 100 mm for cable routing and power distribution. The front door is made of tempered glass with a lock, providing visibility of equipment status while preventing unauthorized access. Removable and lockable side panels allow for easy access during installation, and top and bottom cable entry points with brush strips keep dust out while allowing cables to pass through cleanly.

What stands out

• Two-part swing frame design for effortless rear access to equipment
• 27U capacity with 60 kg static load rating for switches, patch panels, and servers
• Tempered glass front door with lock for security and visibility
• Removable, lockable side panels for convenient installation and maintenance
• Top and bottom cable entry with brush strips to maintain cleanliness
• Passive ventilation with fan unit cut-outs for optional active cooling
• Welded steel frame with RAL 7035 light grey powder coating for durability

Technical details

• Rack units: 27U
• External dimensions (W x D x H): 600 x 600 x 1330 mm
• Usable internal depth: 470 mm
• Rear section depth: 100 mm
• Material: Steel
• Colour: Light grey (RAL 7035)
• Front door: Tempered glass with lock
• Side panels: Removable, lockable
• Mounting type: Wall-mounted
• IP protection rating: IP20
• Static load capacity: 60 kg
• Cable entry: Top and bottom with brush strips
• Ventilation: Passive, with fan unit cut-outs
• Rack profile type: 19-inch adjustable
• Construction: Welded frame
• Compliance: RoHS, EN 60950-1

Our verdict

The Triton RSX-27-XD6-CXX-A1 combines robust construction with a clever swing frame design, making it an excellent choice for installations where rear access is limited. Its 27U capacity and 60 kg load rating handle a wide range of networking gear, while the lockable glass door and side panels keep equipment secure.
