Unidad de distribución de corriente Bachmann 800.2333

The Bachmann Power Distribution Unit 800.2333 is a 1U rack-mount PDU designed for professional IT environments. Housed in a torsionally rigid aluminium profile in 19" format, the unit provides compact power distribution with nine AC outlets fitted as C19 couplers, a 2 m supply cable and support for nominal input voltage of 230 V at up to 16 A. With a depth of 47 mm and a standard 19" width, it can be mounted in standard server racks and integrated into existing installations.

Advantages

The 1U aluminium housing offers mechanical stability with a shallow depth to save rack space while maintaining reliable electrical contacts. Modular socket insertion in the 19" format allows up to nine outlets and supports flexible project-specific configurations. Multifunctional mounting brackets provide several mounting options, including recessed installation, for adaptable placement in racks. The included 2 m cable and C19 couplers make the unit compatible with common data-center equipment.

Suitable for

• Power distribution in server cabinets and network racks
• Data centres and telecommunication cabinets
• IT rooms and equipment closets with limited rack depth

Key specifications

• Model: Bachmann 800.2333
• Form factor: 1 U, 19"
• Dimensions (W × D × H): 482.6 mm × 47 mm × 44 mm
• Outlets: 9 × C19 couplers
• Supply cable: 2 m
• Nominal input voltage: 230 V / 50 Hz
• Maximum current: 16 A
• Housing material: aluminium
• EAN: 4057298006760

How to use

Install the PDU into a 19" rack using the supplied multifunctional mounting brackets; the unit fits into a single 1U space. Connect the 2 m mains cable to a suitable 230 V supply capable of delivering up to 16 A. Plug IT equipment into the C19 outlets, ensuring that the total connected load does not exceed the rated current. For recessed or alternative mounting positions, adjust the brackets according to the rack layout and secure all fastenings to prevent movement.

Recommendations

To ensure safe operation, verify that the rack's power distribution and circuit protection are rated for the combined load of connected devices and observe local electrical codes. Use appropriate grounding and regularly check contacts and mounting hardware for secure connections.
