Unidad de distribución de corriente Bachmann BlueNet BN0500

The Bachmann BlueNet BN0500 is a metered Power Distribution Unit (PDU) with integrated measurement of current, active power, voltage, frequency, phase angle and energy. It features an illuminated LCD for clear readout, an energy meter with reset function that retains its value without mains power, and a compact form factor for installation in racks or workspaces. The device has a nominal input voltage of 230 V, a maximum current rating of 16 A and eight AC outlets, and comes in a black plastic body with a silver aluminium profile.

Advantages

The BN0500 provides accurate monitoring with measurement accuracy of ±1% and a readable illuminated LCD. Its energy meter stores values during power loss and can be reset when needed. The unit includes mounting brackets and screws for straightforward installation and has riveted end caps for secure assembly. Its 2 m cable and compact dimensions (44 mm x 482.6 mm x 44 mm) make it suitable for rack-mounted and workspace setups.

Suitable for

• Rack-mounted equipment power distribution
• Workstation power management
• Environments requiring measured power consumption and basic energy logging
• Small server rooms and IT closets

Key specifications

• Model: Bachmann BlueNet BN0500 (MPN: 800.2054, EAN: 4016514088355)
• PDU type: Metered
• Nominal input voltage: 230 V
• Maximum current: 16 A
• AC outlets: 8
• Measurement accuracy: ±1%
• Integrated measurements: current, active power, voltage, frequency, phase angle, energy
• Display: illuminated LCD
• Energy meter: resettable, retains value without mains power
• Cable length: 2 m
• Dimensions (W x D x H): 44 mm x 482.6 mm x 44 mm
• Colour: Black body with silver aluminium profile

How to use

Mount the PDU using the supplied brackets and screws in the desired rack or workspace position. Connect the BN0500 to a 230 V, 16 A-rated mains outlet using the integrated 2 m cable. Plug equipment into the eight AC outlets. Read measurements and energy data on the illuminated LCD. Use the energy meter reset function when you need to start a new measurement period; the meter will preserve its stored value if mains power is lost.

Recommendations

Ensure the connected load does not exceed the maximum current rating of 16 A and follow local electrical codes when installing the PDU. For continuous monitoring of critical equipment, periodically verify the LCD readings and reset the energy meter only when appropriate for your measurement intervals.
