Unidad de distribución de energía Triton RAB-PD-X06-A1

The Triton RAB-PD-X06-A1 is a 1U power distribution unit designed for reliable rack power management. It offers 8 AC outlets (Type E/F) and a 2 m supply cable, supporting a maximum input current of 16 A per phase and featuring built-in overload protection. The unit is supplied in black and is designed for flexible installation in server cabinets, with options for horizontal or vertical mounting to suit different rack layouts.

Advantages

The Triton RAB-PD-X06-A1 combines a compact 1U form factor with eight Type E/F AC outlets to provide multiple connections within a single rack unit. Its 2 m cable length allows convenient routing to mains connections without additional extension, while overload protection helps prevent damage to connected equipment. The black finish integrates with standard rack equipment and the dual mounting orientation supports both space-saving horizontal placement and vertical distribution along rack posts.

Suitable for

• Server racks and network cabinets in data centers or server rooms
• IT closets and telecom cabinets where multiple AC outlets are required
• Edge computing installations and lab racks with compact power distribution needs

Key specifications

• Form factor: 1U rack-mountable unit
• AC outlets: 8 Type E / F outlets
• Cable length: 2 m supply cable
• Maximum input current: 16 A per phase
• Mounting: horizontal or vertical rack mounting
• Colour: black
• Protection: overload protection

How to use

Mount the PDU in a 19-inch rack either horizontally in a 1U space or vertically along the rack posts according to the available space and cable management plan. Connect the 2 m supply cable to a compatible mains outlet providing the required rated current and ensure the rack earth/ground is properly connected. Plug servers, switches, or other equipment into the eight Type E/F AC outlets. Monitor load levels to avoid exceeding the 16 A per phase limit; the built-in overload protection will act if current exceeds safe levels.

Recommendations

Distribute high-draw devices across phases and avoid connecting all heavy loads to adjacent outlets on the same phase. Verify compatibility of plug type and mains voltage before installation, secure the PDU firmly to prevent strain on the cable, and follow local electrical codes when integrating into a rack power distribution scheme.
