VISION TC-HDMICAT+ extensor HDMI y USB sobre CAT5e/6/6A hasta 70m - 4K@60Hz 4:4:4 - punto a punto - fuente de alimentación individual - KVM con dos puertos USB 1.1

The VISION TC-HDMICAT+ is a professional HDMI and USB extender that transmits uncompressed 4K video and USB signals over a single CAT5e/6/6A cable up to 70 meters. Supporting 4K resolution at 60Hz with 4:4:4 chroma subsampling, this extender delivers pristine image quality for demanding applications. With Power over Cable (PoC), only one power supply is needed, which can be connected at either the transmitter or receiver end. The integrated KVM function with two USB 1.1 ports allows remote control of a computer from the receiver location.

Advantages

• Extends HDMI and USB up to 70m over CAT5e/6/6A
• True 4K@60Hz 4:4:4 for ultra-sharp video
• Single power supply required (PoC) – flexible placement
• KVM functionality with two USB 1.1 ports for keyboard/mouse
• Metal housing for durability and heat dissipation
• Plug-and-play, no software needed

Suitable for

• Digital signage and advertising displays
• Conference rooms and boardrooms
• Education and training facilities
• Retail and hospitality environments
• Control rooms and broadcast studios

Key specifications

• Max Resolution: 3840x2160 @ 60Hz (4:4:4)
• Max Distance: 70m (230ft) over CAT5e/6/6A
• HDMI Version: 2.0, HDCP 2.2/1.4
• Bandwidth: 18 Gbps
• Latency: <1 ms
• USB: 1x USB-B (host), 2x USB-A (device) – USB 1.1
• Power: External DC adapter (included), PoC
• Housing: Metal
• LED Indicators: Power, Link, Data

Recommendations

For optimal performance, use high-quality CAT6 or CAT6A cables. The extender supports point-to-point connection only (one transmitter to one receiver). Ensure the power supply is connected to either the transmitter or receiver, not both.
