VOLTCRAFT XL-AC25SGW conector jack estéreo de 2,5 mm, 3 polos, conexión por soldadura, niquelado, 1 ud. 93025c204

Audio connections often fail at the weakest point: the plug. The VOLTCRAFT XL-AC25SGW 2.5 mm stereo jack plug solves this by providing a robust, solderable connector for custom cable assemblies and repairs. Its 3-pole TRS design carries left and right audio channels plus ground, making it ideal for headphones, microphones, and other stereo devices with 2.5 mm sockets.

Who is it for

This connector is for electronics hobbyists, audio technicians, and DIY enthusiasts who need to build or repair cables for compact audio equipment. It suits anyone working with 2.5 mm stereo jacks, such as on older portable devices, certain headphones, or custom audio projects.

Main features

• 2.5 mm stereo jack plug with 3 poles (TRS) for balanced stereo signals
• Cable mount design with solder termination for secure, permanent connections
• Nickel-plated contacts resist corrosion and ensure reliable signal transfer
• Metal housing with plastic insulation for durability and electrical safety
• Compact size fits tight spaces and portable devices
• Supplied as a single piece for individual repairs or small projects

Specifications

• Connector type: Jack plug
• Connector size: 2.5 mm
• Audio channels: Stereo
• Number of poles: 3 (Tip, Ring, Sleeve)
• Mounting type: Cable mount
• Termination style: Solder
• Contact plating: Nickel
• Housing material: Metal
• Insulation material: Plastic
• Colour: Silver / Black
• Rated voltage: Low voltage audio
• Rated current: Low current audio
• Operating temperature range: -20°C to +70°C
• Application: Audio, headphone, microphone, DIY cable assembly
• Compatibility: Devices with 2.5 mm stereo jack sockets
• Product type: Audio connector
• Quantity per pack: 1 piece

Tips

When soldering, use a fine-tipped iron and heat-shrink tubing to insulate each connection. Ensure the cable clamp is tight to provide strain relief. For best results, match the connector to a cable with an outer diameter that fits the housing's cable entry.
