WAGO 210-281 borne de carril de 2 conductores, CAGE CLAMP, gris, 800V, 24A

The WAGO 210-281 is a compact 2-conductor terminal block designed for DIN-rail mounting (TS 35). Featuring the reliable CAGE CLAMP® connection technology, it ensures fast, vibration-proof, and maintenance-free wiring for solid, stranded, and fine-stranded copper conductors from 0.08 to 2.5 mm² (28–12 AWG). With a rated voltage of 800 V and current of 24 A, this gray polyamide terminal block is ideal for industrial control panels, building automation, and electrical distribution systems.

Advantages

• CAGE CLAMP® spring connection for tool-free, gas-tight terminations
• Compact 2-conductor design saves space on the DIN-rail
• Wide conductor range (0.08–2.5 mm²) for flexible wiring
• High rated voltage (800 V) and current (24 A) for demanding applications
• V-0 flammability rating (UL 94) for enhanced safety
• Operating temperature range -35 to +85 °C

Suitable for

• Industrial control cabinets and switchgear
• Building automation and lighting control
• Electrical distribution and junction boxes
• Machine wiring and sensor/actuator connections

Key specifications

• Number of Conductors: 2
• Connection Type: CAGE CLAMP®
• Mounting Type: DIN-rail (TS 35)
• Nominal Voltage (IEC): 800 V
• Nominal Current (IEC): 24 A
• Rated Impulse Voltage: 8 kV
• Pollution Degree: 3
• Overvoltage Category: III
• Connectable Conductor Material: Copper
• Solid Conductor Size: 0.08 … 2.5 mm² (28 … 12 AWG)
• Stranded Conductor Size: 0.08 … 2.5 mm² (28 … 12 AWG)
• Fine-Stranded Conductor Size: 0.08 … 2.5 mm² (28 … 12 AWG)
• Stripped Length: 8 … 9 mm (0.31 … 0.35 inch)
• Insulation Material: Polyamide (PA)
• Color: Gray
• Flammability Rating: UL 94 V-0
• Operating Temperature: -35 … +85 °C
• Storage Temperature: -35 … +105 °C

Recommendations

For optimal performance, use with WAGO marking strips and test plugs. Ensure proper stripping length (8–9 mm) before insertion. Suitable for use with copper conductors only.
