Wirewin WKUP KAT6A UTP Jack Keystone RJ45, blanco

The Wirewin WKUP KAT6A UTP is a white RJ45 keystone jack designed for high-performance Category 6A networks, delivering up to 10 Gigabit Ethernet speeds and 500 MHz bandwidth. Its tool-less IDC termination and dual T568A/T568B wiring support make it a reliable choice for structured cabling.

Advantages

This keystone jack supports 10GBASE-T over unshielded twisted pair, with gold-plated contacts for consistent connectivity. The snap-in design accepts 22-26 AWG solid or stranded conductors, and it is compatible with Power over Ethernet up to 4PPoE.

Suitable for

• High-speed LAN installations in offices and data centers
• PoE-powered devices such as IP cameras, access points, and VoIP phones
• Keystone wall plates, patch panels, and surface mount boxes

Key specifications

• Connector type: RJ45 female to IDC
• Category: Cat6A (500 MHz)
• Shielding: UTP
• Wiring: T568A/T568B
• Termination: Tool-less, 22-26 AWG
• Contact plating: Gold, 50µm
• Housing: ABS plastic
• Colour: White

Recommendations

For optimal performance, use with Cat6A UTP cable and ensure proper pair untwist length during termination. Verify compatibility with your keystone mounting system before installation.
