ACO Vario Sumidero de suelo parte inferior 75x50 DN 75/DN 50 negro

The ACO Vario Floor Drain Bottom Part 75x50 is a high-quality polypropylene (PP) component designed for use in the ACO Vario modular drainage system. This bottom part features a dual connection outlet (DN 75 and DN 50) with vertical orientation, making it ideal for wet rooms, bathrooms, and utility rooms. It provides a water seal height of 50 mm and a maximum flow rate of approximately 1.2 l/s when combined with a suitable top part. The product is black in color and complies with DIN EN 1253 standards.

Advantages

Durable polypropylene construction ensures long-lasting performance and chemical resistance. The dual outlet size offers flexibility for various pipe connections. Easy to clean with removable components. Compatible with ACO Vario top sections for a complete drainage solution.

Suitable for

• Indoor wet rooms such as bathrooms and utility rooms
• Pedestrian areas with load class K3 (300 kg) when used with appropriate top part
• Installations requiring vertical outlet orientation

Key specifications

• Product Type: Floor Drain Bottom Part
• Material: Polypropylene (PP)
• Outlet Orientation: Vertical
• Nominal Outlet Diameter: DN 50 / DN 75 (Dual Connection)
• Water Seal Height: 50 mm
• Max. Flow Rate: Approx. 1.2 l/s
• Installation Depth: Approx. 115 mm
• Temperature Resistance: Up to 90°C
• Load Class: K3 (300 kg) with suitable top part
• Colour: Black
• Standards: DIN EN 1253

Recommendations

For optimal performance, pair this bottom part with an ACO Vario top section and odor trap (sold separately). Ensure proper installation according to local building codes.
