Adaptador de fibra óptica SC/PC EFB Elektronik 53513.1OM5 verde claro

The EFB Elektronik 53513.1OM5 is a flangeless multi-mode fibre optic adapter with SC/PC connector interfaces. Its light green housing and compact dimensions (27.5 mm × 14.7 mm × 9.2 mm) make it suitable for high-density installations and keystone adapter frames where space efficiency and reliable optical connections are required.

Advantages

This flangeless SC/PC adapter provides a compact footprint for high-density panels, supports secure and repeatable optical mating, and is compatible with keystone adapter frames. The light green color indicates multimode OM5 specification, allowing clear identification in mixed cabling environments. The small size and standard SC form factor facilitate straightforward installation and replacement.

Suitable for

• High-density patch panels and distribution frames
• Keystone adapter frames and modular faceplates
• Multimode OM5 fibre network links
• Data centre and enterprise LAN installations

Key specifications

• Brand: EFB Elektronik
• Model / MPN: 53513.1OM5
• Connector type: SC/PC (multi-mode)
• Fiber grade: OM5 (light green)
• Dimensions (W × D × H): 27.5 mm × 14.7 mm × 9.2 mm
• EAN: 4049759224943

How to use

Insert the adapter into a compatible keystone frame or panel opening and secure it according to the frame’s mounting method. Align SC/PC fibre connectors and push until a positive latch is felt to ensure correct mating. For removal, depress the connector latch and pull straight out. Follow standard fibre handling practices to avoid contamination of end faces and to maintain optical performance.

Recommendations

Keep connector end faces clean and inspect with a fibre microscope before mating; use dust caps when adapters are unused. Install in suitable keystone frames for secure mounting and to maintain high-density cabling organization.
