ATEN PE8324G PDU de rack conmutada 1U 24 salidas, 100-240V, 16A, entrada IEC C20, salidas C13, Ethernet, SNMP PE8324G-AX-G

24 switched IEC C13 outlets in a 1U rackmount form factor, with per-outlet remote on/off/reboot control and real-time energy metering over Ethernet.

Overview

The ATEN PE8324G is a switched rack power distribution unit designed for dense IT environments. It delivers 16A from a single IEC C20 input across 24 C13 outlets, each individually switchable via network. Built-in metering tracks current, voltage, power, and energy with ±1% accuracy, giving you precise insight into power usage at the outlet level.

What stands out

• 24 switched outlets for granular control of connected devices.
• Real-time energy metering with ±1% accuracy.
• Supports TCP/IP, SNMP, SSH, and other standard management protocols.
• Daisy-chain up to 16 PDUs for centralized management.
• Optional environmental sensors for temperature and humidity monitoring.

Technical details

• Input: 100-240V AC, 50/60 Hz, 16A max, IEC C20 inlet.
• Outputs: 24 x IEC C13, 10A max per outlet, 16A total.
• Network: 1 x RJ-45 10/100 Ethernet.
• Management: HTTP/HTTPS, SNMP v1/v2c/v3, Telnet, SSH, and more.
• Overload protection: 16A circuit breaker.
• Form factor: 1U rackmount.
• Operating temperature: 0–50°C.

Our verdict

An ideal choice for data centers needing remote power control and accurate energy monitoring in a space-saving 1U design.
