ATTE IP-5-11-L2 Switch PoE externo de 5 puertos para 5 cámaras IP

The ATTE IP-5-11-L2 is a robust external 5-port PoE switch designed to power and connect up to 5 IP cameras. With 4 PoE+ ports and a total power budget of 60W, it delivers reliable performance for surveillance systems. Its metal housing and wide operating temperature range make it suitable for indoor and outdoor installations.

Advantages

This unmanaged switch offers plug-and-play simplicity, eliminating the need for configuration. It supports IEEE 802.3af/at PoE standards, providing up to 30W per port for high-power devices. The compact design allows desktop or wall-mount placement, and surge protection ensures durability in demanding environments.

Suitable for

• Small to medium IP camera systems
• Surveillance installations requiring PoE+
• Outdoor or industrial environments with temperature extremes
• Desktop or wall-mounted network setups

Key specifications

• 5 Ethernet ports (4 PoE+ 10/100Mbps, 1 uplink 10/100Mbps)
• Total PoE power budget: 60W (up to 30W per port)
• Switching capacity: 1 Gbps
• MAC address table: 1K entries
• Layer 2 unmanaged
• Power input: 48-56V DC
• Operating temperature: -10°C to +50°C
• Metal housing
• Desktop and wall-mountable

Recommendations

For optimal performance, use quality Cat5e or higher Ethernet cables. Ensure the power supply matches the required DC input. This switch is ideal for expanding PoE camera networks without complex configuration.
