AZO Digital Convertidor de tensión PC-100-24V 100W, entrada 10-30 VDC, salida 24 VDC, con aislamiento galvánico, IP21

The AZO Digital PC-100-24V is a high-efficiency voltage converter designed for industrial applications requiring a stable 24 VDC output from a wide 10-30 VDC input range. With galvanic isolation and robust protection features, it ensures reliable power conversion in demanding environments.

Advantages

Galvanic isolation (1.5 kV) protects sensitive equipment from voltage spikes and ground loops. Passive convection cooling ensures silent operation and long lifespan. Compact surface-mount design saves space in control cabinets.

Suitable for

• Industrial automation systems
• Control panels and machinery
• Telecommunications equipment
• Security and surveillance systems

Key specifications

• Input Voltage: 10-30 VDC
• Output Voltage: 24 VDC
• Continuous Output Power: 100 W
• Maximum Output Current: 4.1 A
• Efficiency: >90%
• Isolation Voltage: 1.5 kV (Input to Output)
• Protection: Reverse Polarity, Overvoltage, Short Circuit, Overload
• Enclosure Rating: IP21
• Operating Temperature: -25°C to +55°C
• Cooling: Passive Convection
• Connections: Screw Terminals
• Mounting: Surface Mount
• Housing Material: Aluminum
• Certifications: CE

Recommendations

For optimal performance, ensure adequate ventilation around the converter. Use appropriate wire gauges for input and output connections. This converter is not suitable for outdoor use without additional weatherproofing.
