AZO Digital Convertidor de tensión PC-150-24V 150W, entrada 10-30 VDC, salida 24 VDC, con aislamiento galvánico, IP21

The AZO Digital PC-150-24V is a high-efficiency voltage converter designed to convert a wide input voltage range of 10-30 VDC to a stable 24 VDC output. With a continuous output power of 150W and peak power of 200W, it is ideal for industrial and commercial applications requiring reliable power conversion. The galvanic isolation ensures safety and noise reduction, while the IP21 rating protects against solid objects larger than 12mm. Passive convection cooling ensures silent operation and long lifespan.

Advantages

High efficiency >90% reduces energy loss and heat generation. Galvanic isolation provides electrical safety and minimizes interference. Compact aluminum housing with surface mount design allows easy installation. Built-in protections against overload, short circuit, overvoltage, and thermal events ensure reliable operation.

Suitable for

• Industrial automation systems
• Security and surveillance equipment
• Telecommunications devices
• LED lighting and signage
• Any application requiring stable 24 VDC from a variable DC source

Key specifications

• Input Voltage: 10-30 VDC
• Output Voltage: 24 VDC
• Continuous Output Power: 150 W
• Peak Output Power: 200 W (short-term)
• Efficiency: >90%
• Isolation: Galvanic (input-output)
• Max Input Current: ~15 A at 10V
• Max Output Current: 6.25 A
• Protection: Overload, Short Circuit, Overvoltage, Thermal
• IP Rating: IP21
• Cooling: Passive convection
• Operating Temperature: -25°C to +55°C
• Storage Temperature: -30°C to +70°C
• Input/Output Connector: Screw terminals
• Housing Material: Aluminum alloy
• Mounting: Surface mount
• Standby Current: <20 mA
• Output Ripple & Noise: <100 mVp-p
• Certifications: CE

Recommendations

For optimal performance, ensure the input voltage is within the specified range and the load does not exceed 150W continuous. Use appropriate gauge wiring for screw terminals. This converter is not suitable for outdoor use without additional weatherproofing.
